Friction stir welding (FSW)

Friction stir welding is the optimal joining process for non-ferrous metals with a low melting temperature and for mixed-metal combinations.

Friction stir welding (FSW): the process

Friction stir welding is a process in which a rotating pin is traversed along the contact surfaces between the workpieces. The frictional heat plasticizes the material, which is welded together.

The FSW process is particularly suitable for joining non-ferrous metals with a low melting temperature and for mixed-material joints. Even materials that are difficult to weld or dissimilar materials such as aluminium with magnesium, copper or steel can be friction stir welded.

Sudarea prin fric?iune ofer? o serie de avantaje fa?? de procesele de sudare conven?ionale.

Cea mai înalt? calitate a sudurii
- F?r? defecte de sudur?, cum ar fi pori sau fisuri
- Posibilitatea de ?mbinare a diferitelor materiale
- Consum relativ redus de c?ldur?
- Rezisten?? ridicat? a cordonului de sudur? cu distorsiuni minime de sudare
Eficien?a economic?
- Îmbinarea economic? a geometriilor 3D complexe
- Economii de materiale prin optimizarea componentelor
- Nu se utilizeaz? consumabile cum ar fi gazul de protec?ie ?i sârma tubular?
Tehnologie ecologic?
- Ecologic datorit? consumului redus de energie
- Nu este necesar? extragerea gazelor de ardere sau m?suri antiorbire

Expert article

Friction stir welding as the optimal solution for modern battery housings

Industrial applications of friction stir welding

The Friction stir processing is used in various industries. The spectrum extends from the automotive industry, including the e-mobility market, and aerospace through to the electronics industry.

Friction Stir Welding for General industry
Economical welding of complex 3D seams, e.g. on cooling systems for power electronics or housings for cell phones

Cast components with aluminum sheets or sections

Welds with high conductivity for transformers and batteries

Joining of various material combinations – typically aluminium and its alloys, copper and magnesium alloys
Automotive industry
Economical welding of complex 3D seams, for example on parts of cooling systems, vehicle bodies and powertrains or e-mobility components

Joining of typical 4000/5000/6000 aluminum alloys and also hard-to-weld material combinations, e.g. aluminum sheets, continuously cast sections and cast components
Proces automat e mobilitate
Friction Stir Welding for Aerospace industry
Welding of highly reliable, gas-tight seams, e.g. on aircraft fuselage parts and rocket components

Low heat distortion and special surface characteristics as well as material properties (e.g. tensile strength) at a very high level due to the low joining temperature

Typical materials: high-strength 2000 and 7000 series aluminum alloys
Rail vehicle construction
Joining of side walls and roof assemblies for high-speed trains and of aluminum sheets or sections (double-walled panels)

Highly economical joining thanks to FSW gantry systems and integration of additional machining processes such as milling and drilling

Typical materials: 6000 series aluminum alloys

Proven solutions: KUKA robots in use for FSW applications

Webinar-Special: Advanced Welding Solutions

Gain in-depth insights into rotary friction welding, friction stir welding, and magnetic arc welding in specific webinars.

Watch recording Contact our Experts

Friction stir welding in electric mobility – flexible and cost-efficient

In electromobility, friction stir welding has become firmly established among many OEMs and Tier 1 suppliers, particularly for welding battery housings for electric (EV) and hybrid (HEV) vehicles. The weld seams reliably meet the high requirements for tightness and crash resistance. Robot-based friction stir welding also offers high flexibility at comparatively low investment costs compared to conventional gantry systems. For the production of electric vehicles, KUKA offers a modular friction stir welding cell – a modern and economical solution that can be easily adapted to different production requirements.

KUKA cell4_FSW

Modular friction stir welding robot cell: the modern solution with low investment costs

Dori?i o solu?ie individual??

Avand competent? ?i experien?? ?n sudare, v? consiliem cu pl?cere pentru a g?si solu?ia perfect? pentru cerin?ele dvs. individuale de sudare.

Contacta?i-ne

Perfect friction stir welding: from engineering to service

From feasibility and process investigations to trial welds, FSW tool selection and parameter optimization, including the conceptual design, manufacture and delivery of the system, KUKA offers the entire spectrum of services associated with friction stir welding.

Find out more about FSW Technologie here!
